Coated EPS Block Molding Machine

The machine is equipped with automatic transmission and automatic electronic weighing equipment, printing equipment,The machine is also suitable for lost mold EPS block,The machine is designed by South korean engineer, all of the valves are imported from South Korea.

  • 1. With the use of PLC Controller (Programmable Logic Controller) and Touch Screen, the automatic looping process of opening and closing of the moulds, feeding, heating, heat preservation, cooling, mould ejection, and releasing the final product from the machine will be accomplished.
  • 2. Adopt the auto control system on auto weighing and feeding, auto heeting and cooling.
  • 3. Vacuum system mainly includes vacuum storage tank, vacuum cooling tank and efficient water ring vacuum pump and other components.
  • 4. The machine uses the heating way of top intake, bottom exhaust and cooling way of water spray system.
  • 5. Using high-quality steel and then are welded and heat-treated, sand blasted, shot blasted, the machine is with high strength, no deformation. Block density can reach 6-40kg / m, with high speed, uniform adhesion, low moisture content, the small deformation.
  • 6. Machine cavity is made of stainless steel plate or stainless steel wedge grid structure, with features of energy efficient, easy to disassemble to clean, easy to mold, sheet and good bonding.
  • 7. The machine uses translation mode to open and close the door,with features of nice, fast and efficient way and safe and reliable operation.Eject the block out while the door opened. It is easy to adjust when the mold clamping gap and improve the air tightness of the machine.
  • 8. The machine is equipped with automatic transmission and automatic electronic weighing equipment, printing equipment.
  • 9. The machine is also suitable for lost mold EPS block.
  • 10. The machine is designed by South korean engineer, all of the valves are imported from South Korea.
NO. Items Type/Unit EPSBM3600V/H EPSBM6000V/H
1 Mould Size mm 3660×1230×520 (3040x2)×1230×520
2 Mould Vol m3 2.34 3.88
3 Products Density/Specific Gravity kg/m3 40-60 40-60
4 Production Capacity block/h 3-11 4-12
5 Steam Pressure Mpa 0.6 0.6
6 Steam Inlet DN mm 150 150
7 Air-compressed Inlet DN mm 65 50
8 Supply Power Power kw 30 30
Voltage v 380 380
9 Control Mode   Automatic Automatic
10 Structural Features   Hydraulic Single-door Vacuum Cooling Hydraulic Single-door Vacuum Cooling
11 Control System   PLC with Touch Screen PLC with Touch Screen
12 Max. Outer Dimension Mm 11000×5000×3000 14000×5000×3000
13 Machine Net Weight Tons 13 17
14 Automatic Conveyer Supplied Supplied
15 Electronic Scale Supplied Supplied
16 Printer Optional Optional

EPS products is widely used in packaging industry,food industry,safety industry, building industry,crystallised eps products.
